Rong-Electric MDA400PC4.2+3.2 LED power supply
$31.50
Rong-Electric MDA400PC4.2+3.2 LED power supply Features: High efficiency：≥87% (see figure 4.3) Small Leakage current：≤ 1.0mA (Vin=242Vac) Output voltage range：Vo1:4.12—4.28Vdc Vo2:3.13—3.26Vdc Wide operating temp. range：-30—70℃（+50℃—+70℃ linear de-rated，See Figure 4.2.）…
- Description
- Additional information
Description
Rong-Electric MDA400PC4.2+3.2 LED power supply Features:
- High efficiency：≥87% (see figure 4.3)
- Small Leakage current：≤ 1.0mA (Vin=242Vac)
- Output voltage range：Vo1:4.12—4.28Vdc Vo2:3.13—3.26Vdc
- Wide operating temp. range：-30—70℃（+50℃—+70℃ linear de-rated，See Figure 4.2.）
- Wide Input voltage range：180Vac—264Vac
- Power factor：≥0.95
- Cooling mode：Ventilation cooling
- Protection Features：Output over-voltage protection、over-current protection、short-circuit protection.
Additional information
| Weight | 0.7 kg |
|---|
